Explosion-proof weighing instrument functions

Intrinsically safe explosion-proof instrument, industrial explosion-proof, explosion-proof standard Ex ib IIC T3/T4.

Can be used in chemical, gas, petroleum and other environments with strict explosion-proof requirements.

Removable intrinsically safe explosion-proof battery, 7.4V/6000mA lithium battery pack.

Optional AC explosion-proof power supply.

The instrument can support 90-degree rotation adjustment.

LCD high-resolution display with backlight function, clear reading day and night.

Standard RS232, RS485 communication interface.

Standard 4-way IO output interface.

Standard 4-20mA current loop output interface.

Customized services are available to your actual needs!

Explosion-proof weighing instrument module parameters

Explosion proof sign: Exib ll C T4 Gb.

A/D conversion method: Sigma-Delta.

Maximum calibration graduation: 3000.

Accuracy level: Level lll.

Protection level: IP65.

Sensor power supply: DC5V士2%.

Input impedance: >10MΩ.

Zero adjustment range: 0~5mV.

Gain input range: 1~10mV.

Non linearity: ±0.003%F·S(measurement and control 15bps).

Maximum display accuracy: 1/100000.

Power supply: AC 220V/50~60Hz.
